High Efficient Tablet Coating Machine

High Efficient Tablet Coating Machine

Applying: It is kind of equipment integrating elegance, high efficiency, energy-saving,safety, easy to clean, which is applied for coating traditional Chinese andWestern tablets and pills (including micro-pills, small pills,water-bindered pills,drip pills and granulated pills)with sugar, organic...

Product Details

Applying:


It is kind of equipment integrating elegance, high efficiency, energy-saving,safety, easy to clean, which is applied for coating traditional Chinese andWestern tablets and pills (including micro-pills, small pills,water-bindered pills,drip pills and granulated pills)with sugar, organic film, water soluble film, slow and controlled release film in the fields of pharmacy, food and biology etc. Themachine is equipped with the programmable PLC (machine and person interface), with which its operation process and process parameters such as negative pressure and temperature can be automatically controlled. It is easy to operate, with reasonable and advanced process during run of the machine.Main machine, cleaning system, hot-air cabinet, exhaust cabinet and the thermostatic mixing drum are all made of imported high quality, stainless steel,which conforms to "GMP" requirements.The tablets make complicated and constant track movement with easy and smooth turning and frequent exchanging in a clean and closed drum of the film coating machine. The coating mediums stirred in the constant temperature stirring drum are sprayed on tablets through the spray gun at the inlet under the action of crawler pump. Meanwhile hot air up to 100,000 level filtration are inhaled through the air distributing pipe at the center of the drum and flowed through tablets around the fan blade. Under the action of air exhaust and negative pressure, hot air are exhausted from the another side of the air distributing pipe and discharged after dust abatement. So these coating mediums on the surface of tablets get dry quickly, forming a coat of firm, fine and smooth film. Automatically controlled by PLC, it is in normal operation.

Features:

1. The control system consisting of PLC and HMI is designed reasonably with flexible programming, meeting various pharmaceutical process requirements with reliable work and stable performance and conforming to GMP requirements.  2. Under the action of the streamlined diversion plate mixer, the tablets or pills turn smoothly and exchange frequently, so that the occurrence of the tablets or pills dropping from high positions and colliding is eliminated, broken edges are avoided and the rate of finished products is enhanced. The upper surface of the diversion plate is narrow, avoiding the adhesion of dressing onto its surface, saving the dressing and improving medicine quality.  3. The return flow pipe is canceled in the constant pressure variable peristaltic pump. The rotation radius of the roller changes with the change of pressure, so that the output paste and paste volume are automatically balanced, the atomizing effect is stabilized, the spray system is optimized, the blocking of the spray gun is avoided, the dressing is saved. In addition, it is easy to clean without any dead corners.  4. It adopts the new type spray gun with even atomizing, large spraying area, adjustable direction. The nozzle is not affected by the loading volume, the device for cleaning the blocked spray gun can ensure continuous coating, shorten coating time and save coating dressing.  5. Quantitative display and control of technical parameters are realized. SOP operation can be compiled to guide the operation by using quantitative indicators and ensure the consistency of quality of each batch of medicines,fully meeting GMP requirements


Parameters:


Technical Type

40(D)E

10D

Load Capacity (kg)

40

10

Revolutions(R/Min)

2.0-18

3.0-19

Machine dimensions kw

1.1

0.55

Machine dimensions
(L*W*H) mm

1100*850 *1470

900*700 *1400

Diameter of Coating drum mm

780

500

Power of Air Exhaust Cabinet Motor kw

2.2

0.75

Air exhaust flow m3/h

3517

1285

Power of Hot Air Cabinet Motor kw

0.75

0.37

Hot air flow m3/h

1285

816

Weight of Main Machine kg

500

200

Overall Dimensions of Air Exhaust Cabinet mm

900*800
*1500

750*600
*1130

Overall Dimensions of Air Exhaust Cabinet mm

820*720
*1750

750*600
*1130

Air Consumption
Pressure MPa

>0.39

>0.39

 Air Consumption m3/min




We have different capacity high efficient tablet film coating machine for you choose
