Automatic Capsule Filling Machine For Liquid Oil Pellet Powder

Furis Machinery Group is one of the most reliable manufacturers and suppliers of automatic capsule filling machine for liquid oil pellet powder in China. Our factory offer high quality equipment made in China with competitive price. Welcome to place an order.



Applying:

This capsule filling machine is used for filling the liquid powder pellet into the hard capsule and gluing the hard capsule automatic

Features:

1. It is of touch screen control, multi-system integrated and its degree of automation is higher;



2. Conventional feeding and vacuum feeding are optional in accordance with applicable scene;



3. Material-lacking overload is under automatic protection which can ensure materials’ smooth supply;



4. Capsule’s baiting, orientation and in-place are accurate and speed can be controlled;



5. Sizing treatment is even and secondary sizing treatment technology locks sealing effect;



6. It adopts highly-sensitive temperature sensor, by which, temperature of glue box can be real-time controlled;



7. Glue box adopts asbestos heat insulation for design, by which, operations are safe and reliable;



8. It adopts precision pneumatic control system which ensures glue box’s working smoothly up and down and forward and backward;



9. Glue box and machine body adopt separating and closing design, by which, it can be easily disassembled and easily cleaned;



10. Its originally created function of capsule chain plate positive and negative conveying can effectively extend conveying distance;



11. It adopts reciprocating conveying mechanism, it can be naturally dried which does not affect drug properties inside capsule;



12. Its part contacted with drug is manufactured fully by stainless steel which conforms to GMP standard.

Parameters:

Model	NJP-600
Capacity ( capsule/min)	600pcs/min
Capsule Size	No.00#~ 2# and safety capsules a ~ e
Filling rate	=>99%
Power	7.75kw
Vacuum pump	0.02-0.06Mpa
Noise	<75dBA
Filling error	>300ml ≤±3％
Working temperature	21℃±3℃
Relative humidity of working environment	40～55％
Optional function	Filling granule device(optional)
Oversize and weight of machine	3565×1100×2100mm, 1500kg

The auto capsule filling machine for powder and pellet parameters:

Model	Capacity ( capsule /min)	Capsule Size	Filling rate	Power	Vacuum pump	Noise	Dust collector	Oversize and weight of machine
NJP-200	200	No.00-5	=>99%	3.5kw	0.02-0.06Mpa	<80dBA	700m3/H, 2X105pa, 350*700*1000mm, 40kg	870*670*1900mm, 700kg
NJP-400	400	No.00-5	=>99%	5kw	0.02-0.06Mpa	<80dBA	700m3/H, 2X105pa, 350*700*1000mm, 40kg	870*670*1900mm, 700kg
NJP-800	800	No.00-5	=>99%	5.5kw	0.02-0.06Mpa	<80dBA	700m3/H, 2X105pa, 350*700*1000mm, 40kg	970*820*1900mm, 900kg
NJP-1200	1200	No.00-5	=>99%	7kw	0.02-0.06Mpa	<80dBA	700m3/H, 2X105pa, 350*700*1000mm, 40kg	1020*860*1970mm, 1000kg
NJP-1500	1500	No.00-5	=>99%	7kw	0.02-0.06Mpa	<80dBA	700m3/H, 2X105pa, 350*700*1000mm, 40kg	1500*1040*1970mm, 1300kg
NJP-2500	2500	No.00-5	=>99%	7kw	0.02-0.06Mpa	<80dBA	700m3/H, 2X105pa, 350*700*1000mm, 40kg	1500*1040*1970mm, 1500kg
NJP-3800	3800	No.00-5	=>99%	7.6kw	0.02-0.06Mpa	<80dBA	700m3/H, 2X105pa, 350*700*1000mm, 40kg	1500*1450*2100mm, 2000kg
NJP-7500	7500	No.00-5	=>99%	13.5kw	0.02-0.09Mpa	<80dBA	900m3/H, 2X105pa, 350*700*1000mm, 40kg	1700*1450*2150mm, 3800kg
